About this vehicle
Year:
2023
Condition:
New
Make:
Club Car
Power Type:
Gas
Model:
Onward
Color:
Metallic Cashmere
Date Built:
05/17/2023
Location:
Seven Points
Features
Premium seats
Premium Windshield
Side Mirrors
Turn Signals
USB Charger
Description
Specifications for Onward® 4 Passenger
ENGINE 429 cc Kohler, Overhead Valve (OHV) with EFI
HORSEPOWER 14.0 hp (10.3 kW) rated @ 3600 RPM per SAE J1940
BATTERIES One 12-volt
STEERING SportDrive™ — Self-compensating double reduction helical rack & pinion
FRONT SUSPENSION Independent leaf spring w/dual hydraulic shocks
BRAKES Self-adjusting, rear wheel mechanical drum
PARK BRAKE Foot actuated, 3-position
BODY AND FINISH Front: Painted TPO; Rear: Painted Surlyn
TIRES 10″ Mercury wheel – 205/55-10 Kenda® Loadstar tires
LXWXH 108 x 48 3/4 x 71 inches
WHEELBASE 65 1/2 inches/Metric
GROUND CLEARANCE 4 1/2 inches/Metric
FUEL TANK CAPACITY 6.0 gal (22.7 L)
TREAD–FRONT & REAR Front/Rear: 36/40 inches;/Metric
TOTAL VEHICLE WEIGHT 795 lb/Metric
FRAME TYPE AlumiCore™ — Ladder-style aluminum box beam
SPEED RANGE 19 mph (30 kph)
ELECTRICAL FEATURES Front LED headlights with LED accent running lights, rear LED tail & brake lights, front & rear turn signals, state of charge or fuel meter & horn
